Price
US $2
Model
Control Penal IGBT 400A 500A Industrial Arc W
Min. Order
1 piece

Item specifics

Rated Input Voltage
3PH ~ 400V ±15%
Rated Output
400A/36V
Max Open Circuit Voltage
19.93KVA
Effiency
85%
Warranty
1 year warranty
Dimensions
680x310x650mm
Weight
45KG

Product review

Description

  • /FEATURES

    Quick Specs
    Application:
    Construction industry
    Metal workshops
    Agriculture
    Repair and maintenance
    Processes:
    Stick (SMAW)
    Input Power:400V, 3-Phase
    Amperage Range:400i: 20-400A
    500i: 20-500A/630i: 20-630A
    Rated Output at 40℃ (104℉):
    400i: 400A at 36V @60% Duty Cycle
    500i: 500A at 40V @60% Duty Cycle
    630i: 630A at 44V @60% Duty Cycle
    Weight:
    400i:45KG/ 500i:50KG/ 630i:50KG

    General View of Control Panel

    ARC-400i-500i-630i-▏MMA-Welders_03

    1.Arcforce rotary dial
    To adjust the welding parameters to the
    electrode type used. Infinite setting from rutile
    (soft arc) to cellulose (hard arc) electrode types.
    2.Hotstart current rotary dial
    Increased ignition current during the set hotstart
    period to optimise the arc ignition.
    3.Welding current setting rotary dial
    Infinite setting of the welding current across the
    whole power range.




    Hot Start

    Hot start function reliably ignites the electrode and melts
    perfectly to ensure the best quality even at the start of
    the seam. This solution makes lack of fusion and cold welds
    a thing of the past and significantly reduces weld reinforcement.
    Adjust the hot start current here and the time here.

    PROTIG-350CT-400CT-500CT-▏TIG-Welders_03

    Arcforce correction (welding characteristics)

    MIG-350i-500i-▏MIG-Welders_13

    During the welding process, arcforce prevents the electrode sticking in the weld pool with increases in current.
    This makes it easier to weld large-drop melting electrode types at low current strengths with a short arc in particular.

  • /SPECIFICATIONS



    Technical specifications



    Item NoARC-400iARC-500iARC-630i
    Rated Input Voltage3PH ~ 400V ±15%3PH ~ 400V ±15%3PH ~ 400V ±15%
    Max. Load Power Capacity19.93KVA27.68KVA39.41KVA
    Rated Duty Cycle(40oC) 60%400A/36V500A/40V630A/45.2V
    100%315A/32.6V400A/36V500A/40V
    Welding Current/Voltage Range20A/20.8V~400A/36V20A/20.8V~500A/40V20A/20.8V~630A/45.2V
    Open Circuit VoltageMIG: 70V~80VMIG: 70V~80VMIG: 70V~80V
    Power Factor0.850.850.85
    Efficiency85%85%85%
    MMA Arc Force1%~100%1%~100%1%~100%
    Hot Start Time0.1S~2S0.1S~2S0.1S~2S
    Hot Start Current1%~100%1%~100%1%~100%
    Dimension680x310x650mm680x310x650mm680x310x650mm
    Weight45KG50KG50KG

  • /ACCESSORIES

    For Standard accessories
    01
    Hand helmet Brush/hanner
    2
    Electrode holder with cable 2M
    For Optional accessories
    02
    Air Carbon Gouging Torch
  • /RESOURCES
