plasma cutting machine PROCUT 105MAX
- Model
- PROCUT 105MAX
Item specifics
- Input Voltage
- 3PH ~ 400V ±15%
- Duty Cycle Rating 40℃(105℉)
- 105A@100%
Review
Description
DETAILS
PROCUT 105MAX
The PROCUT 105MAX plasma system has the duty cycle and performance needed for tough industrial cutting jobs. Delivering superior cut capabilities on 32 mm (1-1/4") thick metals, it also offers the latest technological innovations, that based the 100% duty cycle, the mechanized pierce capability could be up to a 22 mm (7/8”).
CUTTING CAPACITY
|
Capacity
|
Thickness
|
Cut Speed
|
|
Cutting
|
||
|
Dross Free(CNC)
|
16mm
|
900mm/min
|
Pierce* | 22mm | |
Recommend(Hand Cutting) | 32mm | 500mm/min |
|
Severance (Hand Cutting)
|
50mm
|
125mm/min
|
*Pierce rating for handheld using or with CNC torch height control
Maximum Productivity
· Finish jobs faster with cut speeds three times greater than oxyfuel on 12 mm (1/2”) mild steel
· Superior cut quality let you spend less time on grinding and edge preparation
· 100% duty cycle maximizes your cutting time
· Multiple, easy-to-use torch styles let you tackle a wide variety of jobs using the same system
Superior Mechanized Cutting Capacity
· Fast and clean cut (dross-free) up to 16mm, and maxim pierce up to 22mm for mild steel
· It can provide versatility for portable automation, X-Y table cutting, extended reach cutting, and robotic cutting.
Lower Operating Costs
· Consumable life up to four times longer than other systems in this amperage range;
· Electrode end-of-life detection protects the torch and workpiece from damage by automatically stopping power when the electrode is overused.
More Reliability And Stability
· Designed with 100% duty cycle for the most demanding production environments;
· Designed and tested as the TOPWELL PROCUT series product for superior reliability in the most demanding cutting environments.
Torch Information
For machine jobs
PMX105 full-length machine torches work with a wide variety of CNC cutting tables, track cutters, and pipe-cutters. Mini machine torches are perfectly suited for lighter tables and pipe cutting situations where the full-length torch is too long..
VIDEO
SPECIFICATIONS
Machines
|
Product Name
|
PROCUT 105MAX
|
Product Weights & Dimensions
|
Dimensions(L*W*H)
|
680*310*650mm
|
|
Net Weight
|
48KG
|
Basic Specification
|
Input Voltage
|
380V/400V, 3PH, 50/60Hz
|
|
Input Power
|
16KVA
|
|
Rated Output Voltage
|
160VDC
|
|
Max Output Current
|
105A
|
Open Circuit Voltage (OCV) | 350VDC |
Operating Temperature | -10℃~40℃ |
Duty Cycle Rating 40℃(105℉) | 105A@100% |
Torch | Manual: PX102/6m CNC: TP105/7.5m |
Recommended Gas Inlet Flow Rate/Pressure | 460 scfh, 7.7 scfm @ 85 psi |
