topwell air/air mild steel plasma cutting machine POWERCUT-100HD
- Model
- PowerCUT-100H
Item specifics
- Rated Input Voltage
- 340-460V, 3-PH, 50-60Hz
- Rated Output Currant
- 30-100A
- Max Open Circuit Voltage
- 15KVA
- Rated output voltage
- 120VDC
- Duty cycle rating40°C(105°F) 380V /400V, 3PH :
- 100% @80A
- Operating temperature
- -10°C~40°C
- Arc ignition mode
- HF or Not HF
- Warranty
- 1 year warranty
- Dimensions
- 680X310X650MM
- Weight
- 42KG
Review
Description
-
PowerCUT-100H
Classical, Reliable, Powerful, wildly used for Manual cutting, Gouging or even CNC cutting
-
Application:
Home workshop
Metal workshops
Light fabrication
Repair and maintenance -
These Materials:
Mild Steel
Brass
Stainless Steel
Copper
Aluminum -
Input Power: 340-460V, 3-Phase
Amperage Range: 30-100A
Rated Output at 40℃ (104℉):
100A at @60% Duty Cycle
Weight: 42KG
Excellent Cutting Performance
- A powerful 60% duty cycle to handle long time production cutting in the toughest environments.
- Optional HF or Non-HF plasma Torch, more flexible.
- The torch is versatile and durable enough to handle a variety of jobs.
- Finish jobs faster with cut speeds two and three times greater than other traditional cutting process.
- Speed less time on secondary operations due to superior cut and gouge capacity.
- Topwell’s long-life consumable deliver operating cost that is less than half the competition.
General View of Control Panel
-
1.Ammeter/Voltmeter Display
2.Encoder Control
3.Mode:2T(STD)/4T(HOLD)
CUTTING CAPACITY
Capacity Thickness Cut speed Recommended cut 30mm 500mm/min Severance（Hand cutting） 45mm 125mm/min Pierce* 16mm *Pierce rating for handheld or with CNC torch height control
Gouge capacity Removal rate Groove profile Plasma gougingn Typical gouge 8.8kg/h 5.8mm Dx 7.1mm W
Non-HF Arc Ignition system
- Torch off.
- By pressing the trigger the torch will be fed by the current thus causing a temporary short circuit betweenelectrode and tip.
- The air then pushes up the small piston, thuscreating, between the electrode and the tip, the distance needed to strike the pilot arc.
- By positioning the torch on the part to be cut, theplasma arc will strike.
Torches with pilot arc cut in without high frequency.
Less electromagnetic disturbance, with consequent absence of problems for any electronic, radio, television, telephone and computer systems in the vicinity of the cutting positions.
Less electric stress on the torch - and on the respective connecting cables - due to the absence of the high voltage necessary for striking the arc Greater simplicity in comparson with other torches(without high frequency) on the market,with a consequent decrease of the risks of jamming in the mechanical pneumatic movement for striking the arc. Subject to wear (electrode, tips, nozzles, diffusers etc.), thanks to the better cooling of the torch obtained by reducing the insulating thicknesses (without endangering the safety parameters).
-
-
Item No PowerCUT-100H Input voltages (±15%) 380V, 3PH, 50/60Hz
400V, 3PH, 50/60HzMax. Load Power Capacity 15KVA Rated output voltage 120VDC Max output current 100A Open circuit voltage (OCV) 280VDC Duty cycle rating40°C(105°F) 380V /400V, 3PH : 60% @100A
100% @80AOperating temperature -10°C~40°C Dimensions 680*310*650mm Weight 42kg Recommended gas inlet flow rate/pressure Cutting: 460 scfh, 7.7 scfm @ 85 psi
Gouging: 480 scfh, 8.0 scfm @ 70 psiArc ignition mode HF or Not HF Certifications CE, ROHS Warranty Power supplies have a 3-year warranty - ACCESSORIES
Handheld plasma torch: TP80 torch
CNC torch: TP105
Handheld gouging torch: TP120
Mechanical gouging torch: TP120
-
-
