315 amp Portable mma inverter welding machine ARC-315i(cellulose)
315 amp Portable mma inverter welding machine ARC-315i(cellulose)
315 amp Portable mma inverter welding machine ARC-315i(cellulose)
315 amp Portable mma inverter welding machine ARC-315i(cellulose)
315 amp Portable mma inverter welding machine ARC-315i(cellulose)
Price
US $2
Model
ARC-315i
Min. Order
1 piece

Item specifics

Rated Input Voltage
3PH ~ 400V ±15%
Rated Output
315A/32.6V
Open Circuit Voltage
70V~80V
Effiency
80%
Warranty
1 year warranty
Dimensions
540x240x480mm(LxWxH)
Weight
20KG

Product review

Description

  • /FEATURES

    Quick Specs
    Application:
    Construction industry
    Metal workshops
    Agriculture
    Repair and maintenance
    Processes:
    Stick (SMAW)
    Input Power:380V, 3-Phase
    Amperage Range: 20-315A
    Rated Output at 40℃ (104℉):
    315A at 32.6V @60% Duty Cycle
    Weight:20KG

    General View of Control Panel

    ARC-315

    1.Ammeter/Voltmeter Display
    2.Arcforce rotary dial
    To adjust the welding parameters to the electrode
    type used.Infinite setting from rutile (soft arc)
    to cellulose (hard arc) electrode types.
    3.Hotstart current rotary dial
    Increased ignition current during the set
    hotstart period to optimise the arc ignition.
    Setting from 20 A to 200 A.
    4.Welding current setting rotary dial
    Infinite setting of the welding current across
    the whole power range.




    Hot Start

    Hot start function reliably ignites the electrode and melts
    perfectly to ensure the best quality even at the start of
    the seam. This solution makes lack of fusion and cold welds
    a thing of the past and significantly reduces weld reinforcement.
    Adjust the hot start current here and the time here.

    PROTIG-350CT-400CT-500CT-▏TIG-Welders_03

    Arcforce correction (welding characteristics)

    MIG-350i-500i-▏MIG-Welders_13

    During the welding process, arcforce prevents the electrode sticking in the weld pool with increases in current.
    This makes it easier to weld large-drop melting electrode types at low current strengths with a short arc in particular.

  • /SPECIFICATIONS





    Technical specifications



    Item NoARC-315i
    Rated Input Voltage3PH ~400V ±15%
    Max. Load Power Capacity16.0KVA
    Rated Duty Cycle(40oC)60%315A/32.6V
    100%250A/30V
    Welding Current/Voltage Range20A/20.8V~315A/32.6V
    Open Circuit Voltage70V~80V
    Power Factor0.8
    Efficiency80%
    MMAArc Force1%~100%
    Hot Start Time0.1S~2S
    Hot Start Current1%~100%
    Dimension540x240x480mm
    Weight20 KG

  • /ACCESSORIES

    For Standard accessories
    01
    Hand helmet Brush/hanner
    2
    Electrode holder with cable 2M
    For Optional accessories
    4
    TIG torch: TIG-26
