- Rated Input Voltage
- 3PH ~ 400V ±15%
- Rated Output
- Open Circuit Voltage
- Rated Duty Cycle(40℃) 60%
- Max. Load Power Capacity
- 1 year warranty
The total solution of TIG welding
Application:Metal fabrication workshops
Shipyards and offshore industry
Chemical and process industry
Steel structure workshops
Processes:DC TIG (GTAW)
AC TIG (GTAW)
MIX TIG (GTAW)
Input Power: 340-460V, 3-PhaseAmperage Range: 5-320A
Rated Output at 40℃ (104℉):
320A at 22.8V @60% Duty Cycle
Conventional Pulsed TIG
Typically from 0.2 to 10 PPS. Provides a heating and cooling effect on the weld puddle and can reduce distortion by lowering the average amperage. This heating and cooling effect also produces a distinct ripple pattern in the weld bead. The relationship between pulse frequency and travel speed determines the distance between the ripples. Slow pulsing can also be coordinated with filler metal addition and can increase overall control of the weld puddle.
High Speed Pulsed TIG
In excess of 40 PPS, Pulsed TIG becomes more audible than visible—causing increased puddle agitation for a better as-welded microstructure. Pulsing the weld current at high speeds — between a high Peak and a low Background amperage — can also constrict and focus the arc. This results in maximum arc stability, increased penetration and increased travel speeds.
Standard Square Wave
The Standard Square Wave offers fast transitions between EN and EP for a responsive, dynamic, and focused arc with better directional control. It forms a fast-freezing puddle with deep penetration and fast travel speeds.
The Sine Wave a soft arc with the feel of a conventional power source. It provides good wetting action and actually sounds quieter than other waves. Its fast transition through the zero amperage point also eliminates the need for continuous high frequency.
MIX TIG CONTROL
Features of MIX TIG:
The AC current can get a very good clearance, and DC current can get a deeper penetration.
Use the MIX TIG we can get an excellent Arc Concentration,
can be carried out the excellent welding performance from thin to thick plate.
1) Nice weld appearance, deep penetration.
2) Excellet Arc Concentration..
3) Substantially reduce the electrode consumption.
MIX TIG Frequency (Hz):
the cycle time of MIX
TIG in 1 second. Adjustable range: 0.1-10Hz.
MIX TIG Balance (DC) %:
DC Balance (%) = (tad/Tmix) x 100
AC Waveshape Controls
Item No MASTERTIG-320CT Rated Input Voltage 3PH ~ 230V ±15% Max. Load Power Capacity TIG: 9.13KVA MMA: 10.38KVA Rated Duty Cycle(40℃) 60% TIG: 320A/22.8V MMA: 250A/20V 100% TIG: 250A/20V MMA: 200A/28V Welding Current/Voltage Range TIG: 5A/10.2V~300A/22V MMA: 20A/20.8V~250A/30V Open Circuit Voltage 70V~80V Power Factor 0.85 Efficiency 85% TIG Pulse Peak Current 5A~250A TIG; Pulse Pulse Frequency 0.2Hz~200Hz TIG; Pulse Pulse Width (Ratio) 1~100% TIG; AC TIG AC Frequency Range 20Hz~250Hz TIG; AC TIG AC Clean Width (AC Balance) +40~-40 TIG; AC TIG AC Clean Ratio (AC Bias) % +30~-50 TIG; MIX TIG MIX Frequency 1Hz~5Hz TIG; MIX TIG DC Balance (%) 20~80 TIG; Arc-starting Current 5A~250A TIG; Crater-filling Current 5A~250A TIG; Current Up-slope Time 0.1S~15S TIG; Current Down-slop Time 0.1S~15S TIG; Pre-Gas Time 0.1S~15S TIG; Flow-Gas Time 0.1S~15S TIG; Spot Arc Time 0.1S~10S MMA Arc Force 10A~250A MMA Hot Start Time 0.1~3S MMA Hot Start Current 10A~250A Dimension (LxWxH) 960x420x900mm Weight 75KG Water-cooling Unit: WC-150 Operating Voltage 230V 50/60Hz Rated Power 260W Cooling Power 1.5KW(1L/MIN) Maximum Pressure 0.3MPA/60HZ Recommended Cooling Liquid 20%~40% ethanol/water Tank Volume 6.5L
- For Standard accessories
Electrode holder with cable 2M
Earth clamp with cable 2MFor Optional accessories
BINZEL ABITIG ® GRIP 26
Argon gas regular
Water-cooling unit: WC-100
