ALUTIG-200P/200MV AC DC Pulse TIG Welder ALUTIG-200P for aluminum
ALUTIG-200P/200MV  AC DC Pulse TIG Welder ALUTIG-200P for aluminum
ALUTIG-200P/200MV  AC DC Pulse TIG Welder ALUTIG-200P for aluminum
ALUTIG-200P/200MV  AC DC Pulse TIG Welder ALUTIG-200P for aluminum
ALUTIG-200P/200MV  AC DC Pulse TIG Welder ALUTIG-200P for aluminum
ALUTIG-200P/200MV  AC DC Pulse TIG Welder ALUTIG-200P for aluminum
Price
US $2
Model
ALUTIG-200P/200MV
Min. Order
1 piece

Item specifics

Rated Input Voltage
1PH ~ 230V ±15%
Rated Output
200A/18V
Open Circuit Voltage
70V~80V
Effiency
80%
Warranty
1 year warranty
Dimensions
540x240x480mm
Weight
23KG

Product review

Description

  • /FEATURES

    Quick Specs
    Application:
    Metal Fabrication
    Maintenance and Repair
    Auto Body
    Light Industrial
    Processes:
    DC TIG (GTAW)
    AC TIG (GTAW)
    MIX TIG (GTAW)
    Stick (SMAW)
    Input Power:200P:230V,1-Phase
    200MV:110-220V,1-Phase
    Amperage Range: 5-200A
    Rated Output at 40℃ (104℉):
    200A at 18V @60% Duty Cycle
    Weight:23kg

    General View of Control Panel

    ALUTIG-200P_03

    1.Welding Process
      DC TIG
      AC TIG
      MIX TIG
      DC MMA
    2.Memory Display
    3.Memory
    4.Ammeter/Voltmeter Display
    5.Encoder Control
    6.Arc Ignition type
      HF Impulse
      LIFT Arc
    7.Pulser Control
      Peak Current : 5A~200A
      Base Current :5A~200A
      Pulse Frequency : 0.2Hz~200Hz
      Pulse Width (Ratio) : 1~100%
    8.Mode
      2T(STD)
      4T(HOLD)
      Spot Arc

    9.Sequencer Control
      Arc-starting Current: 10A~160A
      Crater-filling Current: 5A~200A
      Current Up-slope Time: 0.1S~10S
      Current Down-slop Time:0.1S~15S
    10.Pre-Gas Time: 0.1S~10S
      Flow-Gas Time: 0.1S~15S
    11.AC Waveshape types
      Advanced Squarewave
      Soft Squarewave
      Sine Wave
      Triangular Wave
    12.Arc Ignition Polarity   DC+/DC-
    13.MIX TIG
      MIX Frequency: 0.1Hz~5Hz
      DC Balance: (%) 10~90
    14.AC Waveshape
      AC Frequency Range : 20Hz~200Hz
      AC Clean Width (AC Balance) : +40~-40
      AC Clean Ratio (AC Bias) % : +30~-50


    MIX TIG Control

    Features of MIX TIG:

    The AC current can get a very good clearance, and
    DC current can get a deeper penetration. Use the
    MIX TIG we can get an excellent Arc Concentration,
    can be carried out the excellent welding performance
    from thin to thick plate.
    1) Nice weld appearance, deep penetration.
    2) Excellet Arc Concentration.
    3) Substantially reduce the electrode consumption.

    MASTER-TIG-350CT-400CT-500CT-▏TIG-Welders_0_11

    MIX TIG Frequency (Hz):

    the cycle time of MIX
    TIG in 1 second. Adjustable range: 0.1-10Hz.

    MASTER-TIG-350CT-400CT-500CT-▏TIG-Welders_0_14

    MIX TIG Balance (DC) %:

    DC Balance (%) = (tad/Tmix) x 100

    MASTER-TIG-350CT-400CT-500CT-▏TIG-Welders_0_16



    MIX TIG Frequency (Hz):


    ALUTIG-200P_17

    AC Frequency control Controls the
    width of theControls the width of the
    arc cone.Increasing the AC Frequency
    provides a more focused arc with
    increased directional control.

    Note: Decreasing the AC Frequency
    softens the arc and broadens the
    weld puddle for a wider weld bead.

    MASTER-TIG-350CT-400CT-500CT-▏TIG-Welders_0_21

    ALUTIG-200P_23

    AC Balance Control
    Controls arc cleaning action.
    Adjusting the % EN of the AC wave
    controls the width of the etching
    zone surrounding the weld.

    Note: Set the AC Balance control
    for adequate arc cleaning action
    at the sides and in front of the weld
    puddle. AC Balance should be fine
    tuned according to how heavy or
    thick th eoxides are.

    MASTER-TIG-350CT-400CT-500CT-▏TIG-Welders_0_26

    ALUTIG-200P_28

    Independent AC Amperage Control
    Allows the EN and EP amperage
    values to beset independently.
    Adjusts the ratio of EN to EP
    amperage to precisely control heat
    EN amperage controls the level of
    penetration, while EP amperage
    dramatically effects the arc cleaning
    action along with the AC Balance
    control.


    MASTER-TIG-350CT-400CT-500CT-▏TIG-Welders_0_30



  • /SPECIFICATIONS



    Technical specifications



    Item NoALUTIG-200PALUTIG-200MV
    Rated Input Voltage1PH ~ 230V ±15%1PH ~ 115V/230V ±15%
    Max. Load Power CapacityTIG: 5.62KVATIG: 4.55KVA
     MMA: 6.60KVAMMA: 5.33KVA
    Rated Duty Cycle(40oC) 60%TIG: 200A/18VTIG: 200A/18V
     MMA: 160A/26.4VMMA: 160A/26.4V
    100%TIG: 160A/26.4VTIG: 160A/26.4V
     MMA: 130A/25.2VMMA: 130A/25.2V
    Welding Current/Voltage RangeTIG: 5A/10.2V~200A/18VTIG: 5A/10.2V~200A/18V
     MMA:20A/20.8V~160A/26.4VMMA:20A/20.8V~160A/26.4V
    Open Circuit Voltage70V~80V70V~80V
    Power Factor0.80.8
    Efficiency80%80%
    TIGPulsePeak Current5A~200A5A~200A
    Base Current5A~200A5A~200A
    Pulse Frequency0.2Hz~200Hz0.2Hz~200Hz
    Pulse Width (Ratio)1~100%1~100%
    AC TIGAC Frequency Range20Hz~250Hz20Hz~250Hz
    AC Clean Width (AC Balance)+40~-40+40~-40
    AC Clean Ratio (AC Bias) %+30~-50+30~-50
    MIX TIGMIX Frequency:1Hz~5Hz1Hz~5Hz
    DC Balance: (%)20-8020-80
    Arc-starting Current10A~160A10A~160A
    Crater-filling Current5A~200A5A~200A
    Current Up-slope Time0.1S~15S0.1S~15S
    Current Down-slop Time0-15S0-15S
    Pre-Gas Time0-15S0-15S
    Flow-Gas Time0-15S0-15S
    Spot Arc Time0-10S0-10S
    MMAArc Force10A~160A10A~160A
    Hot Start Time0.1~3S0.1~3S
    Hot Start Current10A-160A10A-160A
    Dimension (LxWxH)540X240X480mm540X240X480mm
    Weight (KG)23KG23KG

  • /ACCESSORIES

    For Standard accessories
    4
    TIG torch: TIG-26
    2
    Electrode holder with cable 2M
    For Optional accessories
    01
    Argon gas regular
    02
    Water-cooling unit: WC-100
    02
    Foot Pedal
    03
    Trolley:ST-7
    02
    Hand-hold Remote TIG torch
    01
    TIG torch: TIG-26
