Topwell 250amp double pulse mig welder PROMIG-250SYN DPULSE
- Model
- PROMIG-250SYN DPulse
Item specifics
- Rated Input Voltage
- 1PH~230V ±15%/3PH~400V ±15%
- MAX.Load Power Capacity
- 11.72KVA
- Rated Output
- 250A/26.5V
- Open Circuit Voltage
- 70V-80V
- Effiency
- 80%
- Wire-feed Mechanism
- 4Rollers
- Wire Feed Speed Range
- 2-25m/min
- Warranty
- 3 year warranty
- Dimension
- 790x250x650mm
- Weight
- 32KG
Review
Description
-
PROMIG-250SYN DPulse
Synergy, Pulse and Double Pulse MIG
-
Application:
Metal Fabrication
Maintenance and Repair
Auto Body
Light Industrial,Workshop -
Processes:
Pulse Process For M.S/AL
Double Pulse Process For M.S/AL
MIG/MAG
Flux-Cored
MMA(Stick) -
Input Power:
Rated Output at 40°C (104°F):
1PH ~ 230V ±15%/3PH ~ 400V ±15%
250A /26.5V/60% Duty Cycle
Weight: 32KG
Advanced Features
-
Multi-Process Capable - Welds flux-cored, stick, TIG, pulsed MIG, and advanced processes like Double Pulse MIG*.
-
Pulse MIG Process - Welds Mild steel, 4XXX and 5XXX series aluminum for superior quality welding.
-
Double Pulse MIG Process - Delivers a staked dime appearance when welding mild steel and aluminum.
-
Synergic Control - Set weld procedures with one control.
-
Professional 4-Rollers Drive System - Allows for constant wire feed speed and consistent welds.
Pulse MIG
-
The Pulse MIG process works by forming one droplet of molten metal at the end of the electrode per pulse. Then, just the right amount of current is added to push that one droplet across the arc and into the puddle. The transfer of these droplets occurs through the arc, one droplet per pulse.
-
It minimizes warping and burnthrough on thin materials, not only for Aluminum, but also for Mild Steel. Moreover, it delivers ultra low spatters which is outstanding for Mild Steel welding.
Professional 4-rollers drive systems
-
Four-rollers drive systems deliver the electrode to the welding torch. It provides a stable wire speed and is popular for industrial applications.
-
4-Rollers wire feeder also provides continuous push force to the wire and ensure an accurate and positive wire feed speed, which is important for aluminum.
-
-
Item No PROMIG-250SYN Pulse Rated Input Voltage 3PH ~ 400V ±15% Max. Load Power Capacity 11.72KVA Rated Duty Cycle(40℃) 60% MIG: 250A/26.5V MMA: 250A/30V TIG: 250A/20V 100% MIG: 200A/24V MMA: MMA: 200A/28V TIG: TIG: 200A/18V Welding Current/Voltage Range MIG: 10A/14.5V~300A/29V MMA:10A/20.8V~250A/30V TIG:5A/10.2V~250A/20V Open Circuit Voltage 70V~80V Power Factor 0.8 Efficiency 80% Pre-Gas Time Preset Flow-Gas Time Preset Wire-feed Mechanism 4 Rollers Wire-feed Speed Range 0~25 m/min Wire Spool Capacity 300mm (15kg) Filler Wires (mm) for Fe : 0.8~1.2 mm For Stainless steel: 0.8~1.2mm For Aluminum: 0.8~1.2mm Dimension 790X250X650mm Weight 32KG - For Standard accessories
MIG torch:MIG-24
Electrode holder with cable 2M
Earth clamp with cable 2MFor Optional accessories
BINZEL MB EVO PRO 24
Argon gas regular
or co 2 gas regular with heater
Push-pull Troch:
QTLB-24KD/36KD
TIG Troch:TIG-26
-
-
Q:Are you a factory or a trading company?
A: We are factory with more than 10 years manufacturing experience and we provide perfect OEM and after-sale service.
Q:How can I pay my order?
A: We accept T/T, Western Union, Alibaba Trade Assurance payments. For those orders less than 1000USD, we accept PayPal to pay.
Q:How about your warranty?
A: We offer 3-year product life guarantee ,and a generous 1 year warranty on al purchases that begins with the bill of lading.
Q: Do you have a CE certificate?
A: For every model of machine, it has a CE certificate.
Q:How can I get the quotation?
A: We usually quote within 24 hours after we get your inquiry. If you are urgent to get the price,please send the message on trade management or call us directly
